Schücode Commissioning instructions – Schüco DCS Touch Display
26
Dok-Nr.10000432116_01
INFORMATION
DCS Touch Display power supply
A power supply in the form of PoE+ is required in order to operate the DCS Touch Display.
This is either provided by a suitable switch or by the IP secure connector. The maximum length of an
Ethernet cable between the DCS Touch Display and the switch or IP secure connector is 50 m.
DCS Touch Display circuit breakers
All inputs and outputs of the DCS Touch Display are protected against voltages above 60 V DC and
42 V AC. The „OUT24V“ output also has circuit breakers to protect against external supply,
short circuiting and reverse polarity.
SELV electrical circuit
The relay output must only be used for SELV electrical circuits. A SELV electrical circuit in accordance
with IEC/EN 60950-1 must be securely isolated (e.g. by means of double insulation) from a
dangerous electrical circuit (e.g. 230 V or 110 V mains supply circuit) and must not exceed the vol-
tage value of 60 V DC or 42.4 V ACpeak (30 V ACeff).
7.2.1. Connection to lock technology
If no IP secure connector is used, proceed as follows to connect an electric lock to the DCS Touch
Display:
1. Connect the green control wires (ST) of the SafeMatic to the „A4“ socket („OUT COM“) and the
wires that supply power to the „A3“ socket („OUT NO“).
2. Ensure that the cables are laid correctly.
7.2.2. Dismantling
In order to be able to remove the Schüco DCS Touch Display, the alarm must be deactivated and the
unlocking mechanism released. The Schüco DCS Touch Display installation tool (Art. No. 263 272) is
required for the latter and is supplied with the Schüco DCS Touch Display.
INFORMATION
Removing the Schüco DCS Touch Display
It is essential that you observe the steps for deactivating the alarm prior to removal, as otherwise the
alarm mode will be activated. If the DCS Touch Display is connected to an IP secure connector in
the alarm mode, the connection between the DCS Touch Display and the building‘s network will be
disconnected when an attempt is made to remove the DCS Touch Display improperly. In this way, any
unauthorised access from outside via this network cable is successfully prevented.
To unlock the DCS Touch Display, proceed as follows, provided that it has already been
commissioned or connected to an IP secure connector:
