INSTALLATION
AIR COMPRESSOR - OWNER'S MANUAL
K1
1 L1 3 L2 5 L3
A1 A2
96 NC 95 NC
X1
FT1
PENL1
L1: "PHASE 1" CONDUCTOR
N: "NEUTRAL" CONDUCTOR
PE: "PROTECTIVE" CONDUCTOR (GROUND)
MAKE LEADS "L1", "N" AND "PE" TO "1 L1", "5 L3" AND "X1.3"
RESPECTIVELY, KEEPTING THE OTHERS CONDUCTORS;
MANUFACTORY WIRES LEADS:
"96 NC" CONECTED TO "A1"
"5 L3" CONECTED TO "A2"
"1 L1" CONECTED TO "RED BUTTON"
"RED BUTTON" CONECTED TO "X1.2"
"X1.2" CONECTED TO "PRESSURE SWITCH"
"PRESSURE SWITCH" CONECTED TO "X1.1"
"X1.1" CONECTED TO "95 NC"
2 T1 4 T2 6 T3
"2 T1" CONECTED TO "3 L2"
"X1.4" AND "X1.5" CONECTED TO "PRESSURE SWITCH" AND "MOTOR"
"4 T2" AND "6 T3" CONECTED TO "MOTOR”
CUSTOMER WIRES LEADS:
WARNING:
- TURN OFF POWER AND DISCONNECT ALL SUPPLY SOURCE BEFORE SERVICING
X1
SINGLE - PHASE
1
2
1
2
3 4 5
3 4 5
WIRING PROCEDURE
AIR COMPRESSOR - OWNER'S MANUAL
41
D.O.L. STARTER
TECHNICAL DATA 15120HW60X
442
Black
(pump)
Gray
(tank)
1,500
ELECTRIC MOTOR OIL CAP.
WEIGHT WITH MOTOR
DISCHARGE
SIZE
BELT
SIZE
COLOR
REF.
Volume
ml
Kg
2P
VOLTAGE V[ ]
hp kW
15120HW60X
150
2-B
1’’
MODEL
Ø PULLEY
rpm
1,065 5.9
inches
mm
60 1,700 175 12
DISPLACEMENT
MAX. PRESSURE
cfm psig bar
Geom. Volume
l/min
427 113
TANK
gal
975
lbs
in qt.
1,580
15
Three-phase
208/230/460
11.3
51.2/1,300
18.9/480
12.6/320
21.6/550
8.6/218 4.7/120
Ø 19.7/500
24.4/620
28.7/73078.3/1,990
13.3/340
Ø 0.55/14
47.3/1,200
1'' BSP
4 x Ø 5/8/16
29.0/740
Note: dimensions in inch/mm.
