44
AIR COMPRESSOR - OWNER'S MANUAL
TECHNICAL DATA 20120HWV80X
620
Black
(pump)
Gray
(tank)
4,500
ELECTRIC MOTOR OIL CAP.
WEIGHT WITH MOTOR
DISCHARGE
SIZE
BELT
SIZE
COLOR
REF.
Volume
ml
Kg
2P
2P
VOLTAGE (V)
hp kW
20120HWV80X
145
2-B
1’’
MODEL
Ø PULLEY
rpm
910 5.7
inches
mm
80 2,264 175 12
DISPLACEMENT
MAX. PRESSURE
cfm psig bar
Geom. Volume
l/min
427 113
TANK
gal
1,370
lbs
in qt.
4,620
20
Three-phase
208/230/460
15
57.5/1,460
18.9/480
13.5/34425.5/650
9.6/244 4.7/120
Ø 21.2/540
30.7/780
25.6/650
37.8/960
78.3/1,990
13.3/340
4 x Ø 5/8/16
Ø 0.55/14
47.3/1,200
1'' BSP
Note: dimensions in inch/mm.
INSTALLATION
5
AIR COMPRESSOR - OWNER'S MANUAL
0
1
2
3
4
5
6
7
8
9
A
B
C
DD
SUPPLY 230/460* VCA-60Hz
LINE CIRCUIT
COMPRESSOR MOTOR
START LINE
AND CONTROL
PROTECTION
MULTIWIRE DIAGRAM
5, 7.5, 10, 15 and 20 hp - THREE PHASE
2
3
2
4
6
5
1
3
230/460* V 60HZ
R
T
A2
K1
A1
95
96
FT1
22
P1
21
X1.2
X1.1
1
S
6
2
4
5
1
3
12
B1
11
P
ELECTRICAL DIAGRAM
FT1
K1
M
3~
GROUND
F1 F2 F3
Customer's responsibility
* According to the product version
**
*
***
** Customer’s responsability according to the
product version.
T
460V
230V
TAG
DESCRIPTION
F1
F2
F3
P1
T
K1
FT1
M
B1
X1
FUSES
PRESSURE SWITCH
COMMAND TRANSFORMER
MAIN CONTACTOR
OVERLOAD RELAY
ELECTRIC MOTOR
EMERGENCY BUTTON
TERMINAL BLOCK
*** For the model 580VL20X - NS, the electric leads
are carried through directly to the electric
components without the terminal blocks (X1).
To Next Page
