Assembly and settings
8 02.00 | MMS 22-PI1-EX/MMSK 22-PI1-EX | Assembly and Operating Manual | en | 1566685
4 Assembly and settings
NOTE
The assembly instructions in this chapter are generally
applicable.
Module-specific assembly instructions for the sensor can be
found in the Assembly and Operating Manual for the module,
which can be downloaded at schunk.com
4.1 Special conditions for ATEX applications
The sensor should be installed so that it is protected from UV
light, mechanical hazards, condensation and ingress of moisture.
The sensor must be provided with a fuse that corresponds to the
rated current. The breaking capacity of the fuse must correspond
to the possible short circuit current of the supply source.
For MMS(K) 22-PI1...EX, the fixed connection cable should be
connected in non-explosive areas or in a certified housing in
compliance with an ignition protection type according to EN
60079-0 or in a certified housing according to EN 60079-31.
4.2 Mechanical connection
CAUTION
Property damage due to incorrect bending radius!
The product may get damaged if the cable's bending radius is
less than the minimum.
l
Static: 10 times the cable diameter.
l
Dynamic: 15 times the cable diameter.
CAUTION
Risk of damage to the sensor during assembly!
l
Observe the maximal tightening torque.
Ferromagnetic components change the sensor's switching
positions, e.g. adapter plate made of construction steel. For
ferromagnetic adapter plates:
l
First, install the module on the adapter plate.
l
Then adjust the switching position of the sensor.
