Fig ure 2-3. Air craft Instruments (Sheet 1 of 4)
Limitations
Pilot's Flight Manual
SCHWEIZER
Model 269C Helicopter
2-10
Reissued: 16 Jan 2019
2-12. IN STRU MENT MARK INGS
RED YEL LOW GREEN
RED IN DI CATES MAX I MUM YEL LOW IN DI CATES GREEN IN DI CATES
AND MIN I MUM OP ER ATING CAU TION ARY OP ER ATING NOR MAL OP ER ATING
LIMITS; THE EDGE OF A RANGE. RANGE.
RED LINE IS THE LIMITING
VALUE; THE POINTER
SHOULD NOT ENTER THE
RED DURING NOR MAL
OP ER A TIONS.
NOTE
The in stru ments shown on this page are no lon ger in
pro duc tion.
U.S. GALS PSI °F X 100
FUEL FUEL PRES SURE
500°F RED RA DIAL
14 AND 35 PSIG RED RA DIAL
450° TO 500°F YEL LOW ARC
14 TO 30 PSIG GREEN ARC
230°TO 450°F GREEN ARC
PSI °F AMPS
OIL PRESS OIL TEMP
60 AND 100 PSIG RED RA DIAL 260°F RED RA DIAL
60 TO 90 PSIG GREEN ARC 100° TO 250°F GREEN ARC
This Document contains technical data subject to EAR. See WARNING and classifications on first page.
FAA Approved
