Horizontal stabilizer, vertical fin, and tail light CHECK
TAILBOOM, RIGHT SIDE
Tailboom for damage or dents CHECK
Tailboom supports and fittings for cracks,
looseness, security, deformation, or damage CHECK
Tailboom support strut end fitting for cracks,
deformation, or damage CHECK
ENGINE - RIGHT SIDE
Belt drive lower pulley bearings CHECK
Place hand be tween en gine and V-belt
drive cover; grasp forward edge of
pulley (lower coupling drive) and try
to move at right angles to shaft.
Observe bearing to determine if
bearing inner race is a tight fit on
lower pulley shaft.
Idler pulley for smooth rotational movement
and fore and aft freedom of movement CHECK
Clutch control cable, spring assembly, and
lower end of spring retainer
Clutch en gaged: With a flash light care -
fully check clutch ca ble where it en ters
spring as sem bly for any bro ken strands
at the end of the in ter nal swaged fit ting.
No bro ken strands per mit ted; Check
spring ten sion mark.
Clutch en gaged and dis en gaged: Check
lower end of spring re tainer tube for
wear and wear de pos its.
Clutch dis en gaged: Check spring as -
sem bly for free dom. Check pul ley
bracket for cracks and se cu rity.
Fuel quantity level; match with fuel gauge CHECK
Fuel tank cap seal for proper condition CHECK
Normal Procedures
Pilot's Flight Manual
4-8
Reissued: 16 Jan 2019
This Document contains technical data subject to EAR. See WARNING and classifications on first page.
SCHWEIZER
Model 269C Helicopter
FAA Approved
CSP Book 1 CSP-C-1.indd 92 8/4/19 12:45 PM
