Schwinn Crewmaster - Assembly Instructions (Continued); Install Seat and Bushings; Connect Rail to Frame Wires

10
3. Slide Seat onto Rail Assembly and Install Bushings
Note: The bushings and hardware (*) are pre-installed and not on the Hardware Card. Remove ziptie from the rail.
4. Connect Wires from Rail Assembly to Frame Assembly
Note: Remove rubberbands from the cables on the Rail Assembly. Do not crimp the cables.
4
5
*
*
6mm
5mm
