Schwinn Crewmaster - Assembly Instructions (Continued); Install Console on Mast; Attach Handle to Pull Strap

12
7. Install the Console on the Mast
NOTICE: Remove the rubberbands from the cables and connect the cables from the mast to the Console cables. Do not
crimp the cables. Insert the bolt through the hole between the ribs (7a) on the side of the Console Bracket.
8. Attach the Handle to the Pull Strap
NOTICE: Push the Handle into the pull strap loop (1a). Remove the ziptie and cardboard tube from the pull strap. Do not
allow the pull strap to retract by itself.
G
D F
8
1a
1a
