FRONT FENDER - if equipped
The front fender is mounted at the fork crown. There are two ways in which to mount
your front fender. The rst is the caliper brake mounng system (see Fig. 3.45), and the
second is the 10mm nut and bolt system (see Fig. 3.46). Idenfy the mounng system
used on your bicycle and follow the given instrucons for that parcular type of
mounng system.
(Fig. 3.45) Caliper Brake Mounng System
First remove the front wheel from your bicycle. Remove the hex nut from the caliper
brake bolt on the rear of the fork, and slide the brake assembly from the fork. Place
the fender assembly onto the fork making sure the aachment holes and fender
bracket holes line up. Reaach the caliper brake making sure that the brake arms
are on each side of the fender. Tighten the bolt unl secure.
(Fig. 3.46) 10mm Nut and Bolt Mounng System
First remove the front wheel from your bicycle. Place the fender assembly onto the
fork making sure the aachment holes and fender bracket holes line up. Aach the
fender with the 10mm hex bolt and nut. Tighten the bolt unl secure.
ASSEMBLY
3.45
3.46
46
