PEGS
Some models may come equipped with 2 or 4 pegs. To install pegs, DO NOT loosen or
remove axle nuts. Check to make sure axle nuts are properly ghtened before installing
pegs. Thread the pegs on the axle over the axle nut, and insert a screwdriver or similar
tool through the peg holes and ghten by turning the peg with the tool. (Fig. 3.47)
Periodically check to make sure pegs are ght.
TRAINING WHEELS
Aaching training wheel brace to bicycle
There are three dierent braces used to aach the training wheels to the bicycle:
the c-shape brace, the at brace and the at brace with stabilizer. Determine which
brace was included with your bicycle and follow the given instrucons for that
parcular brace.
C-Shape Brace
Remove the outer axle nut and washer from the rear wheel axle. Place the brace
stabilizer washer onto the axle and align the washer so that the notch on the washer
ts into the rear frame drop out. Next, place the C-shaped wheel brace onto the axle
and replace the washer and axle nut. Tighten the axle nut securely, making sure that
the wheel brace stays in the proper vercal posion. The elongated hole on the wheel
brace allows the training wheel height to be adjusted for proper t. (Fig. 3.48)
ASSEMBLY
