Schwinn Midi Mesa 24 User Manual

©2010
MULTI SPEED BICYCLE
Get to know the parts of your bicycle. This will help with assembly, maintenance, and troubleshoong.
Mul speed bicycles vary greatly. Your model may have addional accessories such as fenders, bags, carriers, etc.
Seat
Rear reflector
Seat post
Quick release
Rear Brake
Gear
control cable
Shi lever
Handlebar stem
Head set
Head tube
Top tube
Down tube
Seat tube
Seat stay
Front derailleur
Chain wheel
Boom Bracket Axle
Crank arm
Tire valve
Front hub
Chain stay
Chain
Rear derailleur
Pedal
Freewheel
Wheel reflector
Rim
Spokes
Tire
Handlebar
Brake lever
Brake control cables
Front reflector
Front brake
Front fork
1.2
PARTS IDENTIFICATION
7
