Schwinn MPower - Tilt Sensor Calibration; Calibration Stages and Steps; Installation Calibration Notice

A12ErrorMessageA18RequiredAngle
A13
Current(Sub)MenuOption
A19
CountdownTimer
A14MenuNumberIndicatorA20
CalibrationStageIndicator
A15
CalibrationStage
A21
CurrentAngle
A16
ProcessStatus
A49
CurrentRPM
A17DeviceID/RequiredRPM
Note:
Displayfieldscanshowdifferentdatafordifferentcalibrationproceduresorfordifferentstages
inacalibrationprocedure.
TiltSensorCalibration
TheC01optioninthePowerCalibrationsubmenuletsyoudotheTiltSensorCalibration.AfteryougototheC01optionandpush
theBacklightbutton,theconsoledoesacheckofthePowerSensortogetthecalibrationstatusandrequirements.
TiltSensorCalibrationhas3stages:Stage1(FullUpPosition–“UP”),Stage2(FullDownPosition–“dn”)andStage0(ZeroG
Calibration–“0G”).TheTiltCalibrationsub-submenuoptionsareUP,dn,0Gand“––”(exit).
WhenyoudotheinitialinstallationofthePowerSensor,dotheFullUpPositioncalibrationandFullDownPosition
calibration.DonotdoZeroGCalibrationforanewPowerSensor(freshoutofthebox).ZeroGCalibrationis
doneatthefactory.
NOTICE:
IfyoumovethebikeafterTiltSensorCalibrationisdone,dotheFullUpPositioncalibrationandFullDownPosition
calibrationagaintocorrecterrorscausedbydifferencesinthefloorlevel.
• •
•
TaptheAVG/ENDorSTAGEbuttontolookattheStageoptions.
• •
•
PushtheBacklightbuttontomakeyourselection.
Note:
Tostopthecalibrationatanypoint,pushandholdtheAVG/ENDbuttonfor3seconds.
