Schwinn Rascal - Assembly; Extend and Secure the Tow Bar

• There are pinch points between the sidewalls and the frame
of the trailer that may cause injury. Fold or unfold the trailer
slowly using cauon.
• Keep children clear when folding or unfolding the trailer.
• Ensure that all locking devices are engaged before use.
TIP! Start assembly with the tow bar side facing up.
❶ Unlock the tow bar by removing the loop on the end of the
locking pin, and removing the locking pin from the tow bar
bracket. Figure 3.1
❷ Rotate the tow bar out and away from the trailer. The tow bar
should be resng on the front of the frame. Figure 3.1
3 Assembly
EXTEND AND SECURE THE TOW BAR
WARNING!
Schwinn Pet Trailer • model 13-SC315 4
Figure 3.1
1
Tow bar bracket
Locking
pin
2
