❸ Re-insert the locking pin through the tow bracket, and lock it
by inserting the end of the loop onto the end of the locking pin.
Figure 3.2
❶ Remove the caps from the ends of the axles.
❷ Insert the axle of the wheel into the hole located on the side
of the trailer frame. Figure 3.3
ATTACH THE WHEELS
5 Schwinn Pet Trailer • model 13-SC315
Figure 3.2 Figure 3.3
Wheels that are not securely locked in place may fall o the
trailer and cause serious injury or death. Always check the
wheels are securely locked in place before use.
WARNING!
3
2
1
