ASSEMBLY
SCIFIT • Scientific Solutions for Fitness • SCIFIT • Scientific Solutions for Fitness •
CI FI T
6
SWIVEL SEAT ASSEMBLY CONT’D
Tools Required:
Step 3: (Buck et Seat Assembly)
a. Align the front holes of the bucket seat with the 3rd set of holes from the front of the handlebar plate,
(see diagram), then loosely screw in (Qty. 1) of item #1 into one of the front holes.
b. Align the other three holes and loosely screw in item #1 into each hole.
c. Tighten all four screws to secure the bucket seat.
1/2” Wrench or socket
Item #1 (x 4)
5/16-18 x 1.25 Serrated Screw
# 1
Rear holes for bucket seat
Front holes for bucket seat
To Next Page
