Scion 2009 xB - Instrument Cluster Indicators

5
OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
4
Low engine oil pressure warning
1
Driver seat belt reminder
1
(alarm will sound if speed is over 12 mph)
Front passenger seat belt reminder
1
(alarm will sound if speed is over 12 mph)
Brake system warning
1
Charging system warning
1
Anti-lock Brake System warning
1
Malfunction/Check Engine indicator
1
Indicator symbols
Open door warning
1
Low Tire Pressure Warning
1
Engine oil replacement reminder
1
Headlight low beam indicator
Turn signal indicator
Headlight high beam indicator
Cruise control indicator
2
Electric power steering system warning
1
Slip indicator
Vehicle Stability Control “OFF” indicator
Airbag SRS warning
1
Instrument cluster
Service indicator and reminder
Speedometer
Tachometer
Fuel gauge
Engine coolant temperature
Odometer and two trip meters
Trip meter reset knob
Multi-information display
Multi-information display control switch
Automatic Transmission shift position indicator
Low fuel level warning
1
1
For details, refer to “Service reminder indicators and warning buzzers,” Section 1-6, 2009
Owner’s Manual.
2
If this light flashes, refer to “Cruise control,” Section 1-7, 2009 Owner’s Manual.
OVERVIEW
Front passenger occupant classification indicator
