Scion 2012 xD - Instrument Cluster

4
OVERVIEW
Low engine oil pressure warning
1
Driver seat belt reminder
(alarm will sound if speed is over 12 mph)
Front passenger seat belt reminder
(alarm will sound if speed is over 12 mph)
Brake system warning
1
Charging system warning
1
Malfunction/Check Engine indicator
1
Indicator symbols
Instrument cluster
Service indicator and reminder
Speedometer
MODE switch
Multi-information display
Tachometer
Shift position indicator
Fuel gauge
1
If indicator does not turn off within a few seconds of starting engine, there may be a
malfunction. Have vehicle inspected by your Toyota dealer.
2
If t
Open door warning
Airbag SRS warning
1
For details, refer to “Indicators and warning lights,” Section 2-2, 2012 Owner’s
Manual.
