4-3. Do-it-yourself maintenance
11 ECU-B 10 A
Gauges and meters, body ECU,
vehicle stability control system
12 RAD NO.1 15 A Audio system
13 DOME 10 A
Interior light, personal light, lug-
gage compartment light, wireless
remote control system
14 AM2 NO.2 7.5 A No circuit
15 ALT-S 7.5 A Charging system
16 TURN-HAZ 10 A
Turn signal lights, emergency
flashers
17 ETCS 10 A
Multiport fuel injection system/
sequential multiport fuel injection
system
18 AM2 30 A
Multiport fuel injection system/
sequential multiport fuel injection
system, starting system
19 STRG LOCK 20 A No circuit
20 SPARE  Spare fuse
21 SPARE  Spare fuse
22 SPARE  Spare fuse
23 EFI MAIN 20 A
Multiport fuel injection system/
sequential multiport fuel injection
system, EFI NO.1, EFI NO.2
24 HORN 10 A Horn
25 IG2 15 A
IGN, METER, IG2 NO.2
26 IG2 NO.2 7.5 A Starting system
27 EFI NO.2 10 A
Air conditioning system, rear O2
sensor, front air flow sensor
28 EFI NO.1 10 A
Multiport fuel injection system/
sequential multiport fuel injection
system, air flow meter
Fuse Ampere Circuit
