332
6-1. Specifications
Brakes
*
1
: Minimum pedal clearance when depressed with a force of 66 lbf (294 N,
30 kgf) while the engine is running
*
2
: Parking brake lever travel when pulled up with a force of 45 lbf (200 N,
20 kgf)
Steering
Tires and wheels
Pedal clearance*
1
3.4 in. (87 mm)
Pedal free play 0.04 0.24 in. (1 6 mm)
Brake pad wear limit 0.06 in. (1.5 mm)
Parking brake lever travel*
2
5 8 clicks
Fluid type SAE J1703 or FMVSS No.116 DOT 3
Free play Less than 1.2 in. (30 mm)
Tire size
P205/55R16 89H, T135/70D17 102M
(spare)
Front and rear tire inflation
pressure
(Recommended cold tire
inflation pressure)
Driving under normal conditions
Front:
35 psi (240 kPa, 2.4 kgf/cm
2
or bar)
Rear:
32 psi (220 kPa, 2.2 kgf/cm
2
or bar)
Spare:
60 psi (420 kPa, 4.2 kgf/cm
2
or bar)
Wheel size 16 6 1/2 J, 17 4T (spare)
Wheel nut torque 76 ft•lbf (103 N•m, 10.5 kgf•m)
