7
Changzhou Sciwil E-
Mobility Technology Co., Ltd.
9
th
Huashan Road, Changzhou, Jiangsu, China- 213022
Fax: +86 519-85602675 Tel: +86 519-8560067
0: Direct Start
1: Kick-to-Start
P10: Drive Mode Setting
0: Pedal Assist – The specific gear of the assist drive decides the assist power
value. In this status the throttle does not work.
1: Electric Drive – The vehicle is driven by the throttle. In this status the power
gear does not work.
2: Pedal Assist + Electric Drive – Electric drive does not work in direct-start status.
P11: Pedal Assist Sensitivity (Range: 1-24)
P12: Pedal Assist Starting Intensity (Range: 0-5)
P13: Magnets Number in Pedal Assist Sensor (5 / 8 / 12pcs)
P14: Current Limit Value (12A by default; Range: 1-20A)
P15: Unspecified
P16: ODO Clearance
Press and hold the up key for 5 seconds and ODO distance will be cleared.
5.5 Communications Protocol：UART
5.6 Key Pad
Key pad position:
To Next Page
