H. REPLACEMENT OF THE WATER PUMP
(AC 125-175)
1. Remove the rear panel by loosening its
screws.
2. Open the storage bin door, locate the plastic
hose on the discharge port of the pump and
disconnect it from the water pump body.
3. Loosen the screw and the yellow green
ground wire.
Trace the pump leads and disconnect them.
4. Loosen the screw securing thr pump plate
to the water reservoir and lift out the water pump
assembly.
5. Loosen the screw and lock washers and lift
the water pump off the bracket.
6. To install the replacement water pump follow
the above steps on reverse.
I. REPLACEMENT OF THE WATER PUMP
(AC 225)
1. Remove front and top panel.
2. Locate the water pump in the front right
corner of the evaporator chamber.
3. Unloose the screw and the yellow green
ground wire. Trace the pump electrical wire leads
and disconnect them.
4. Remove the two screws securing the pump
to sump tank.
5. Through the ice discharge opening remove
first the removable inner plate then trace the
plastic hose and disconnect it from the port of the
pump body.
6. Pull out the pump assy from sump.
7. To install the replacement pump follow the
above steps in reverse.
J. REPLACEMENT OF THE WATER INLET
SOLENOID VALVE
1. Remove the rear panel on models ACM 85
and AC 125-175 and the left side panel on model
AC 225.
2. Close the shut-off valve on the water supply
line and disconnect it from the water inlet fitting at
the rear of the cuber
3. Disconnect the electrical leads from the
solenoid valve.
4. Unscrew the two screws securing the inlet
solenoid valve to the cabinet.
Page 29
5. Remove the corbin clamps and rubber hose;
the valve is now free.
6. To install the replacement water inlet
solenoid valve follow the above steps in reverse.
K. REPLACEMENT OF THE HOT GAS
VALVE COIL
1. Remove rear panel on ACM 85 and
AC 125-175 and the left side panel on model
AC 225.
2. Unloose the nut securing the hot gas valve
coil to its body.
3. Trace the electric wires belonging to the hot
gas valve coil and disconnect them; then lift the
valve coil fron the valve body.
4. To install the replacement hot gas valve coil
follow previous steps in reverse.
L. REPLACEMENT OF WATER DRAIN
SOLENOID VALVE
1. Remove the rear panel.
2. Trace and disconnect the electrical leads
from the water drain solenoid valve coil.
3. Remove the corbin clamps and the plastic
hoses from the valve.
4. Unloose the screws securing the valve to
the frame and remove it.
5. To install the replacement water drain
solenoid valve follow the above steps in reverse.
NOTE. When installing the new valve pay
attention to the water flow direction.
M. REPLACEMENT OF FAN MOTOR
1. Remove front and back panel on models
ACM 85 and AC 125-175 and the front and left
side panel on model AC 225.
2. Remove screws and yellow green ground
wire. Trace the electrical leads of fan motor and
disconnect them.
3. Remove the bolts securing the fan motor
bracket to the cabinet base and then remove the
assembly.
4. To install the replacement fan motor follow
the above steps in reverse.
NOTE. When installing a new fan motor
check that the fan blades do not touch any
surfaces and move freely.
