Basic electr. Amps. Start Amps Watts No of Wires Amp. Fuse
Page 03
SPECIFICATIONS (CONT'D)
Electr. power cons.
Kwh per 24 Hrs
230/50/1 3.2 17 500 10 3 x 1 m/m 10
2
Cubes per harvest: 24 medium
* At 15°C (60°F) water temperature
ACM 85 - CUBER MACHINE SPECIFICATION
Model Cond. Finish Comp. HP
Ice bin cap. Water requirem
Kgs. LTx24 HR
ACM 85 AS Air S/Steel 140*
3/8 14
ACM 85 WS Water S/Steel 380*
FRONT VIEW
HEIGHT (without legs) 790 mm.
HEIGHT (with legs) 930 mm.
WIDTH 457 mm.
DEPTH 523 mm.
WEIGHT 44 Kgs.
