Start Electric power cons.
Amps Kwh per 24 HR
Basic electr. Amps Watts Nr. of wires Amps fuse
SPECIFICATIONS
Model Cond. unit Finish Comp. HP
Ice bin
cap
Water req.
lt/24 HR
AF20 - MACHINE SPECIFICATIONS
Dimensions:
HEIGHT (less legs) 1006 mm.
HEIGHT (with legs) 1126 mm.
WIDTH 969 mm.
DEPTH 613 mm.
WEIGHT 97 Kg.
* A 15°C water temperature
230/50/1 3.2 17 500 11 3 x 1 mm
2
10
S. Steel 3/8 70 Kg.
AF 20 AS Air 120**
AF 20 WS Water 600*
