Start Electric power cons.
Amps Kwh per 24 HR
Basic electr. Amps Watts Nr. of wires Amps fuse
SPECIFICATIONS
Model Cond. unit Finish Comp. HP
Ice bin
cap
Water req.
lt/24 HR
AF80 - MACHINE SPECIFICATIONS
Dimensions:
HEIGHT (less legs) 813 mm.
HEIGHT (with legs) 933 mm.
WIDTH 535 mm.
DEPTH 621 mm.
WEIGHT 72 Kg.
230/50/1 2.2 11 330 7.5 3 x 1.5 mm
2
10
S. Steel 1/4 25 Kg.
AF80 AS Air 53**
AF80 WS Water 300*
* A 15°C water temperature
