Start Electric power cons.
Amps Kwh per 24 HR
Basic electr. Amps Watts Nr. of wires Amps fuse
SPECIFICATIONS
Model Cond. unit Finish Comp. HP
Ice bin
cap
Water req.
lt/24 HR
AF100 - MACHINE SPECIFICATIONS
Dimensions:
HEIGHT (less legs) 1006 mm.
HEIGHT (with legs) 1126 mm.
WIDTH 592 mm.
DEPTH 622 mm.
WEIGHT 72 Kg.
* A 15°C water temperature
230/50/1 2.2 11 400 9 3 x 1.5 mm
2
10
S. Steel 1/4 32 Kg.
AF 100 AS Air 85**
AF 100 WS Water 600*
