Stainless steel 1/2 50 Kg.
Start . Electric power cons.
Amps Kwh per 24 Hr
Model Cond. unit Finish Comp. HP
SPECIFICATIONS
Basic electr. Amps Watts Nr. of wires Amps fuse
230/50/1 4.7 19 950 3 x 1.5 mm
2
16
280*
1400*
EC 206 - CUBER
machine specifications
Cubes per harvest: 72 large / 102 medium / 198 small
* A 15°C water temperature
20.8
17.3
Bin Water req.
Capacity lt/24 HR
EC 206 AS 6 Air
EC 206 WS 6 Water
Dimensions:
HEIGHT (without legs) 779 mm.
HEIGHT (with legs) 859 mm.
WIDTH 1250 mm.
DEPTH 620 mm.
WEIGHT 115 Kgs.
