Line Set
Line Set
• Three tubes
• Reversible
• CME routing
determines which end
goes to CME
– Out the top - use
double-bend ends at
CME
– Out the back - use
single 90 degree ends
at CME
Ends for out the
CME top
Ends for
out the
CME
back
