Scotsman Eclipse CME686 - Page 75

Service Diagnosis
Service Diagnosis
• What happened if?
• The controller is showing a one blink refrigeration
diagnostic light
– This indicates that the ice harvest was very slow and
the controller timed-out on maximum harvest time
– Ice was sensed by the control system
– Likely causes include
• Beginning to freeze up
