Scotsman F0822 - Cabinet Layout

Cabinet Layout
December 2009
Page 4
N0622L, F0822L, N0922L, F1222L, N1322L, F1522L
Remote Low Side User's Manual
24.00
REF.
61
22.00 REF.
55.9
2.92
7.4
6.48
16.5
2.81
7.1
4.30
10.9
16.50
41.9
12.50
31.8
ICE DROP
OPENING
PLAN VIEW
ULTRA SONIC
BIN LEVEL
SENSOR
OPTIONAL
24.00
61
LEFT SIDE VIEW
13.35
33.9
1.59
4
2.63
6.7
14.36
36.5
16.86
42.8
18.81
47.8
21.81
55.4
BACK VIEW
5/8" O.D. REMOTE
SUCTION
CONNECTION
3/8" O.D. REMOTE
LIQUID LINE
CONNECTION
3/4" FPT DRAIN
3/8"FLARE
MACHINE
WATER INLET
120 VOLT CORD
22.00
55.9
27.00
[68.6]
22.89
58.1
FRONT VIEW
Note: Bin Top Cut-outs for
drop zone should include
ultrasonic sensor location
[cm}
In
