Scotsman MC 46 - Horizontal Installation; Vertical Installation

HORIZONTAL INSTALLATION (RECOMMANDED)
450
622
383
A
A
BB
VERTICAL INSTALLATION
A
A
BB
314
408
180
1 FAN MOTOR 2 FAN MOTORS 3 FAN MOTORS
A mm 560 1340 1980
B mm 439 1139 1779
REFRIGERANT CHARGE R404A - Gr
MC 16 MC 16 SHORT MC 46 MF 56 MF 66 MF 86 MV 450 MV 600 MV 800 MV 1000
880 740 1375 1200 2700 5700 1200 1300 3000 3000
