SPECIFICATIONS
Start Electric power cons.
Amps Kwh per 24 HR
Water req.
lt/24 HR
MF 46 - MACHINE SPECIFICATIONS
Dimensions:
HEIGHT (less legs) 645 mm.
HEIGHT (with legs) 650 mm.
WIDTH 535 mm.
DEPTH 660 mm.
WEIGHT 77 Kg.
Model
Finish
Cond. unit
Comp. HP
* A 15°C water temperature
MF 46 AS Air 320*
MF 46 WS Water 1800*
S. Steel 1
Basic electr. Amps Watts Nr. of wires Amps fuse
230/50/1 5.2 29 1200 26 3 x 1.5 mm 16
2
