The length of the defrost or
harvest cycle is controlled
by the PC Board according
to the setting of the DIP
SWITCH 5 and 6 and it is
related to the time that the
machine takes to drop the
evaporating temperature
from 0ºC to -15ºC (time T
2
)
as shown on the table.
A
SWITCH 5 AND 6
D
BC
START UP AND OPERATIONAL CHECKS
NEW MXG SERIES
LENGTH OF HARVEST CYCLE ACCORDING TO THE TIME TO DROP THE
EVAP. TEMPERATURE FROM 0ºC TO -13ºC
LENGTH PROGRAMS
HARVEST
CYCLE A B C D
180” Up to 6’ *** Up to 9’ ***
165” 6’-7’ Up to 3’ 9’-10’ ***
150” 7’-8’ 3’-3’15’ 10’-11’ ***
135” 8’-9’ 3’15”-3’30” 11’-12’ ***
120” 9’-10’ 3’30”-4’30” 12’-13’ Up to 3’
105” 10’-12’ 430”-6’ 13’-15’ 3-4’
90” >12’ >6’ >15’ >4’
