Scotsman Prodigy Plus C0830 - Product Description & Electrical Requirements; Electrical Connection Details

C0322 through C1030
Air and Water Cooled User Manual
November 2012
Page 4
Product Description & Electrical Requirements
Dimensions w" x d" x h" Model Series Electrical
volts/Hz/
phase
Condenser Minimum
Circuit
Ampacity
Maximum
Fuse Size*
22.75** x 24 x 23 C0322SA-1 A or B 115/60/1 Air 12.7 15
C0322SW-1 A or B 115/60/1 Water 11.9 15
C0322SA-32 A or B 208-230/60/1 Air 6.1 15
C0322SW-32 A or B 208-320/60/1 Water 5.6 15
C0522SA-1 A or B 115/60/1 Air 13.8 15
C0522SW-1 A or B 115/60/1 Water 12.2 15
C0522SA-32 A or B 208-230/60/1 Air 7.6 15
C0522SW-32 A or B 208-230/60/1 Water 6.7 15
30.75** x 24 x 23 C0330SA-1 A or B or C 115/60/1 Air 12.7 15
C0330SW-1 A or B or C 115/60/1 Water 11.9 15
C0330MA-32 A or B or C 208-230/60/1 Air 6.1 15
C0330SW-32 A or B 208-230/60/1 Water 5.6 15
C0530SA-1 A or B 115/60/1 Air 13.9 15
C0530SW-1 A or B 115/60/1 Water 12.2 15
C0530SA-32 A or B 208-230/60/1 Air 7.9 15
C0530SW-32 A or B 208-230/60/1 Water 6.7 15
C0530SA-1 C 115/60/1 Air 15.2 20
C0530SW-1 C 115/60/1 Water 13.5 15
C0530SA-32 C 208-230/60/1 Air 7.8 15
C0530SW-32 C 208-230/60/1 Water 6.6 15
C0630SA-32 A or B 208-230/60/1 Air 18.2 20
C0630SW-32 A or B 208-230/60/1 Water 17 20
22.75** x 24 x 29 C0722SA-32 B 208-230/60/1 Air 10 15
30.75** x 24 x 29 C0830SA-32 A or B 208-230/60/1 Air 10.2 15
C0830SW-32 A or B 208-230/60/1 Water 9 15
C0830SA-3 A or B 208-230/60/3 Air 8.4 15
C0830SW-3 A or B 208-230/60/3 Water 7.2 15
C1030SA-32 A or B 208-230/60/1 Air 16 20
C1030SW-32 A or B 208-230/60/1 Water 14.8 15
C1030SA-3 A or B 208-230/60/3 Air 11 15
C1030SW-3 A or B 208-230/60/1 Water 9.8 15
Table notes: Medium cube models have the same electrical characteristics as Small. Series revision code
omitted.
* Or HACR type circuit breakers.
** Maximum width at top panel. Air cooled models add .75" for left side louvers.
