GENIUS LTENGLISH
BIKE OWNERS MANUAL
chainGuide
The Carbon as well as the alloy frames of Genius LT can be fitted with ISCG chainguide
systems.
A set of all spare parts for this action can be ordered via the Scott distribution with
219570 Chainguide ISCG Adaptor Set Genius LT
Details for the assembly on the carbon frames of Genius LT:
Details for the assembly on the alloy frames of Genius LT:
2 Bolt Scott standard
Use 1x 15mm long bolt. Top hole is secured
by chain device bolt. Not for use with guides
with bashplate mounted on ISCG boss.
Triple chain blocker included with bikes
Use 15mm long T25 bolts with
2.5mm spacers
ISCG `05 integrated in frame Chain Blocker mounts with 3x8mm T25 bolts, no spacers
