SCOTT Addict Disc User Manual

ENGLISHENGLISH
•
HEADSET OPTIONS
The Addict Disc/Gravel/CX features a tapered head tube and fork system.
The fork steerer is a 1 1/8” to 1 1/2”.
241901 Headset Syncros Drop-In 1-1/8" - 1-1/2"
•
SEAT POST/CLAMP
The diameter of the seat post is 27.2mm. Please be aware to just use seat clamps with the
size of 30.2mm which fit the frame.
235429 Seatclamp 30.2mm bolt Addict MY14
•
BB STANDARDS/FD MOUNTING DETAILS
The Addict Disc/Gravel/CX is constructed with a Shimano press fit 86 bottom bracket. The
diameter of the cartridge is 41mm
The chain guide from the two-by shifting system is the same as the one from the SCOTT
Scale # 219578, for the front derailleur (FD) hanger use the part# 242435
219578 Chainguide System Scale 2011
242435 Chainguide set Addict CX '16
In case of a one-by shifting system the chain catcher is included in the same kit as the FD
hanger. Part# 242435
242435 Chainguide set Addict CX '16
Chainguide set Addict CX '16
Chainguide set Addict CX '16
Chainguide System Scale 2011
07 |
2016 BIKE USER MANUAL | ADDICT DISC/GRAVEL/CXADDICT DISC/GRAVEL/CX | 2016 BIKE USER MANUAL
| 06

SCOTT Addict Disc Specifications

General

Fork	HMX Carbon
Brakes	Shimano hydraulic disc
Shifters	Shimano
Front Derailleur	Shimano
Rear Derailleur	Shimano
Cassette	Shimano Ultegra
Chain	Shimano
Bottom Bracket	Shimano
Wheelset	Syncros Disc
Tires	Schwalbe One
Handlebar	Syncros Creston
Stem	Syncros
Saddle	Syncros
Seatpost	Syncros Duncan
