The direct and straight cable system on all our full
suspension models allows Smart Cable Routing which is
very resistant against water and dirt.
To change the cables simply unscrew the three cable
brackets on the downtube. [2]
Please note:
Install the washers in between brackets and frame,
otherwise the cables can be squeezed and in worst case
a failure of rear brake or derailleur can occur! [3]
Mechanics hint:
The outer housing of the cables can also be fixed on
the bottle cage with cable fixers, the two brackets
below the cage are not needed anymore. [4]
At SCOTT we are using since 1999 the new location of
the pivot, which has moved forward. This enables the
rider to go uphill standing on the pedals without loosing
power and having optimum grip on the ground.[1]
This pivot was designed at SCOTT using complex com-
puter simulations.
We were confirmed by different and indepenent studies
of bicycling magazines and universities that we really
uncoupled drivetrain and suspension, which causes an
improved energy output of approximately 20%.
The brake away and spring rate remains unchanged and
can be adjusted to style and preference of the rider
itself.
The G-Zero Pivot SCOTT Smart Cable Routing
1 2 3 4
G-Zero pivot Smart Cable Routing aluminum washer mechanical advise
G-ZERO ENDURANCE/
S
PORTSWOMAN
2-3
G-ZERO ENDURANCE/
SPORTSWOMAN
