2023 LUMEN eRIDE | ENGLISH 4
|
LUMEN eRIDE
LUMEN eRIDE
GEOMETRY & TECHNICAL DATA CONT.
Please observe the maximum seatpost insertion
so not to damage the frame.
Small: 150 mm Max Insertion
Medium: 175 mm Max Insertion
Large: 215 mm Max Insertion
X-Large: 255 mm Max Insertion
Please note that on the small sized frame it
is only possible to use a 500 ml water bottle,
with a side entry cage.
