SCOTT SCALE 940 General Manual

ENGLISH
03 |
GENERAL MANUAL | OWNER’S MANUAL 2021
1 Saddle
2 Seat post
3 Seat post clamp
4 Pannier rack
5 Rear light
6 Brake rear
7 Rotor
8 Front derailleur
9 Cassette sprockets
10 Rear derailleur
11 Kickstand
12 Chain
13 Chainring
14 Crank
15 Pedal
16 Stem
17 Bell
18 Handlebars
19 Brake lever
20 Shifter
21 Brake lever/shifter
22 Headset
23 Front lamp
24 Brake front
25 Rotor
26 Fork
27 Hub dynamo
Wheel:
28 Quick-release/
thru axle
29 Spoke
30 Rim
31 Reflector ring
32 Tyre
33 Hub
Frame:
1
Top tube
2
Down tube
3
Seat tube
4
Chainstay
5
Seat stay
6
Head tube
7
Rear shock
Suspension fork:
I
Fork crown
II
Stanchion tube
III
Lower leg
IV
Drop-out
16
18
19
20
22
24
25
28
29
30
32
33
1
2
3
6
7
9
10
12
13
14
II
III
I
1
2
3
4
5
6
7
IV
c

SCOTT SCALE 940 Specifications

General

Brakes	Shimano MT201 Disc
Chain	KMC X12
Saddle	Syncros Belcarra Regular 2.5
Frame	Boost 148x12mm
Fork	RockShox Judy Silver TK, 100mm travel
Shifters	Shimano Deore SL-M6100
Crankset	Shimano FC-MT511-1 / 32T
Cassette	Shimano Deore CS-M6100-12 / 10-51 T
Wheelset	Syncros / 32H
Tires	29x2.25"
Handlebar	Syncros Alloy 6061 / 740mm
Seatpost	Syncros / 31.6mm
BB-Set	Shimano BB-MT500
Rotor	Shimano SM-RT10 CL / 180/F and 160/R
H'stem	Syncros FL1.0
Headset	Syncros OE Press Fit
Hub (Front)	Formula CL-811
Hub (Rear)	Formula CL-3248
Spokes	Stainless Black 15G / 1.8mm
