SCOTT SPARK MY22 User Manual

3
ENGLISH / SPARK TECH MANUAL
MY22 RC // +0,6° head cup //
120mm fork
Small Medium Large X/Large
A HEAD TUBE ANGLE
67.2° 67.2° 67.2° 67.2°
B HEAD TUBE LENGTH
90 mm 90 mm 105.0 mm 115.0 mm
C TOP TUBE HORIZONTAL
562 mm 590 mm 614 mm 642 mm
D STANDOVER HEIGHT
758 mm 765 mm 776 mm 799 mm
E BB OFFSET
-45 mm -45 mm -45 mm -45 mm
F BB HEIGHT
330 mm 330 mm 330 mm 330 mm
G WHEEL BASE
1,129 mm 1,159 mm 1,190 mm 1,231 mm
I BB CENTER TO TOP OF SEATTUBE
415.0 mm 440.0 mm 490 mm 540 mm
J SEAT ANGLE
75.9° 76.1° 76.6° 76.9°
K CHAINSTAY
437.5 mm 437.5 mm 437.5 mm 437.5 mm
L REACH
411 mm 441 mm 471 mm 501 mm
M STACK
602.5 mm 602.5 mm 616 mm 625 mm
N STEM LENGTH
50 mm 60 mm 70 mm 80 mm
P FORK LENGTH
530 mm 530 mm 530 mm 530 mm
Q MAX POST INSERTION
150 mm 175 mm 225 mm 275 mm
CRANK LENGTH
170 mm 175 mm 175 mm 175 mm
MY22 900 // -0,6° head cup //
130mm fork
Small Medium Large X/Large
A HEAD TUBE ANGLE
65.8° 65.8° 65.8° 65.8°
B HEAD TUBE LENGTH
90 mm 90 mm 105 mm 115 mm
C TOP TUBE HORIZONTAL
561 mm 589 mm 613 mm 641 mm
D STANDOVER HEIGHT
759 mm 767 mm 778 mm 801 mm
E BB OFFSET
-43.5 mm -43.5 mm -43.5 mm -43.5 mm
F BB HEIGHT
331.5 mm 331.5 mm 331.5 mm 331.5 mm
G WHEEL BASE
1,145 mm 1,174 mm 1,205 mm 1,236 mm
I BB CENTER TO TOP OF SEATTUBE
415mm 440 mm 490 mm 540 mm
J SEAT ANGLE
75.7° 75.9° 76.4° 76.7°
K CHAINSTAY
437.5mm 437.5mm 437.5mm 437.5mm
L REACH
410 mm 440 mm 470 mm 500 mm
M STACK
607.5 607.5 617.7 mm 627 mm
N STEM LENGTH
50 mm 60 mm 60 mm 70 mm
P FORK LENGTH
540 mm 540 mm 540 mm 540 mm
Q MAX POST INSERTION
150 mm 175 mm 225 mm 275 mm
CRANK LENGTH
170 mm 175 mm 175 mm 175 mm
