Scotts S1642, S1742, S2046 User Manual

Controls - 4
CONTROLS
Controls
Tractor Controls - Gear
A - Throttle/Choke Control
B - Foot Pedal - Brake/Clutch
C - Reverse Implement Option Switch
D - Attachment Lift Lever
E - Locking Lever
F - Transmission Shift Lever
G - Park Brake
H - PTO Drive Lever
I - Ignition Switch
Tractor Controls - Automatic
A - Choke Knob (S2046)
B - Throttle/Choke Control (S1642 and S1742)
Throttle Control (S2046)
C - Foot Pedal - Brake/Clutch/Return to Neutral
D - Reverse Implement Option Switch
E - Attachment Lift Lever
F - Locking Lever
G - Free Wheeling Knob
H - Transmission Shift Lever (Hand Control Units
Only) Cruise Control Lever (Foot Control Units
Only)
I - Park Brake
J - Foot Pedal, Reverse (Foot Control Units Only)
K - Foot Pedal, Forward (Foot Control Units Only)
L - PTO Drive Lever
M - Ignition Switch
D
E
F
G
H
I
C
A
B
E
F
G
I
J
K
M
D
B
C
H
L
A
