16
SHORT SIDE Attaches to
Right Swing Door with Felt Panel
LONG SIDE Attaches to
Right Box Side 1
CAUTION: Leave the Right Box laying on its side for a future step
and until attaching the Center Box.
RIGHT
Swing Door
with
Felt Panel
Remove spacer shelves now and set aside.
13mm Euro Screws
x18
14
Turn box onto Side 2.
Install 5 offset hinges to Right Box Side 1
panel using (15) 13mm Euro Screws.
With two people, attach Right Swing Door with Felt Panel
to Right Box Side 1 using (15) 13mm Euro Screws.
Right Box
Side 1
13mm
Barrel faces down
so that short side of
hinge drops down
below edge of Right
Box.
It is SAFE to use
an Electric Screw Driver
to intall hinges.
To Next Page
