ScrapBox WorkBox 3.0 - Page 18

18
CENTER BOX
5
Fit Shelf 1 into post holes on Divider 1
with finished edge facing up.
Next, Insert (2) Cams at top of Divider 1.
Tighten with Allen Wrench until secure.
Next, assemble the upper section of the center box.
You will come back to the lower section later.
4
Insert (2) Posts into post holes on
top side of Center Box Shelf 1.
x2
Posts
Center Box
Base
Center Box
Shelf 1
Bottom Side
Center Box
Shelf 1
Top Side
Center Box
Divider 1
Locking
Cams
x2
Finished Edge
