SCRAPPER E-STRADA E-8400 - E-Bike Error Code Reference; Clearing Trip Distance Data

13/40
5.8 Error code define
The components of the E-bike system are continuously and automatically monitored.
When an error is detected, the respective error code is indicated in text indication area.
See the definition on the table here below.
Error Code
Error description
21
Current Abnormality
22
Throttle Abnormality
23
Motor Phase Abnormality
24
Motor Hall Signal Abnormality
25
Brake Abnormality
30
Communication Abnormality
5.9 Trip Distance Clearance
After the E-bike system is switched on, hold both the UP button and DOWN button simultaneously for
2s to access general settings menu.
TC represents trip distance clearance settings.
Press the UP/DOWN button to choose Y or N. The default value is N.
To store a changed setting, press the ON/OFF button and access backlight settings.
