PAGE 18
6. INSTALLING GUIDE BAR & SAW CHAIN
5. Fit the chain tensioner nut into the lower hole of the guide
bar, then install the chain cover, and fasten the mounting nut
to finger tightness.
When installing the chain cover, be sure
to fit the hook completely at the rear
end of the cover.
6. While holding up the tip of the bar, adjust the chain ten-
sion by turning the tensioner screw until the tie straps touch
the bottom side of the bar rail.
WARNING
