Calibration
Frequency of recalibration should be based on the
critical nature of those ESD sensitive items handled and
the risk of failure for the ESD protective equipment and
materials. In general, SCS recommends that calibration
be performed annually.
Periodically measure the balance and neutralization
times of the Ionized Air Gun to verify that it is performing
within specifications. These measurements should be
taken using a charged plate monitor such as the SCS
items 711, 770004 and 770005.
Calibration should be performed in accordance with the
ESD Association ionization standard ANSI/ESD-S3.1.
At a line pressure of 30 psi (2 bars) and a distance of
6 inches (15 cm), the neutralization (discharge) time of
±1000V to ±100V should be less than 1 second, and the
balance should be ±30V or better.
Specifications
General
Input Voltage and
Frequency
(120VAC External
Adapter)
AC Power Adapter
Power Input:
120VAC, 60 Hz
Power Output:
24VAC, 500mA
Input Voltage and
Frequency
(230VAC External
Adapter)
AC Power Adapter
Power Input:
230VAC, 50 Hz
Power Output:
24VAC, 500mA
Neutralization
(Discharge) Time at 6",
30 psi
< 1 second
Balance (Oset
Voltage) at 6", 30 psi
±30V
Power Consumption 10 W
Ion Emission Steady-State DC
Emitter Points Tungsten
Audible Noise at 1 m,
30 psi
70 dBA
Ozone < 0.005 ppm
Blow-o Force 41 g @ 30 psi; measured at
3" from a 2" diameter target
Air Hose Static-dissipative
polyurethane, 3/8" outside
diameter; 7' length
Gas Input 20-65 psi, Clean Dry Air
(CDA) or nitrogen
Gas Connection 1/4" male industrial
interchange quick disconnect
Gas Air Filter 99.9% efficient, 0.01 micron
or larger air particles; 99.9%
coalescing efficiency
Mounting Metal mounting plate attaches
to back of console
Enclosure Static-dissipative
polycarbonate
Dimensions (Gun) 8" x 3" x 1"
(20.3 cm x 7.6 cm x 2.5 cm)
Dimensions (Console) 8.5" x 3.0" x 1.6"
(21.6 cm x 7.6 cm x 4.1 cm)
Weight (Gun with Air
Hose)
0.8 lbs (0.4 kg)
Weight (Console) 0.7 lbs (0.3 kg)
Certications cULus, CE, RoHS2
Country of Origin China
