1.3 Accessory Equipment
In addition to the control unit, a plug and cable assembly is needed to provide the inter-connection from the
ST-15C Control Unit to the vehicle. Plug and cable assemblies are available with various plugs conforming
to industry standard configurations and with coiled or straight cables in various lengths.
Scully highly recommends the use of our Sculcon® Junction Box with Plug and Cable assembly. Use of
Sculcon junction box simplifies system installation and provides for easy service of the plug and cable
assembly for maintenance. Wiring the plug and cable assembly directly into the bottom of the ST-15C
enclosure is not recommended and will result in greatly increased maintenance time and difficulty when the
plug and cable assembly requires maintenance.
1.3.1 Sculcon Junction Box with Plug and Cable Assembly
The following model is needed to make connection to a vehicle. The selection is based on the style of
socket used on the vehicles. “B” style plugs connect to “B” style sockets (i.e. 4 J-slots).
Model Description
SC-8B Sculcon Junction Box with 8B Green Plug & Cable. The 8B style plug has 4-bayonet
pins (for attachment to vehicle socket) and 10 contact pins. The SC-8B is available
with either a 9-meter Coiled Cable (P/N 08677) or 6-meter Straight Cable (P/N 09162)
configuration.
Consult factory for additional models.
