ST-47 Groundhog - Technical Manual
General
Page 8.
(TB1)
3
2
1
3
2
1
TB1
GND
NEUT HOT
TB2
5
6
4
7
8 9
MAINS POWER
FUSE
Size: 3AG
250 - 5A
“SLO - BLO”
CONTROL CONTACTS
RATED 5 AMPS
250 Volts MAX
[ ]
Figure 1.2 ST-47 Terminal Block Location Illustration
