SCULPFUN SF-A9 - High-Speed Mode Parameter Recommendation; 40 W and 20 W High-Speed Parameters

SF-A9 Machine User Manual
Note: The following parameters are tested in a laboratory
environment and are for reference only.
There are differences between different materials, and the
parameters will fluctuate.
40W
Material name
power(%)
speed(mm/m)
frequency
Sculpture
Corrugated paper
55%
36000
1
Artificial leather
50%
36000
1
MDF
75%
36000
1
Bamboo
100%
36000
1
Basswood
100%
36000
1
lacquered metal
60%
36000
1
20W
Material name
power(%)
speed(mm/m)
frequency
Sculpture
Corrugated paper
100%
36000
1
Artificial leather
70%
36000
1
MDF
100%
30000
1
Bamboo
100%
15000
1
Basswood
100%
10000
1
lacquered metal
100%
36000
1
SF-A9 40W (laser head power is about 40W) SF-A9 20W (laser head power is about 20W)
19
High speed mode parameter recommendation
