3.The measured temperature value will be displayed on the LCD.
6. Maintenance
6-1. Replacement fuse
Replacing the defective fuse should the done according to the following
procedure.
(1) To avoid electrical shock, remove the test lead and any input signal
before opening the bottom case.
(2) Open the bottom case and then remove the defective fuse and insert a
new fuse of the same size and rating.
(3) Replace the bottom case and install all the screw.
6-2. Replacement battery
When meter display the battery must be replace to maintain
normal operation.
(1) Disconnect and remove all test probes from any live source and meter.
(2)Open the bottom case by screwdriver.
(3) Replace with one fresh 9 volt battery.
(4) Replace the bottom case and install all the screw.
SHANGHAI SDAR ELECTRONIC INSTRUMENTS CO., LTD.
NO. 1158, KAIMING RD., SONGJIANG INDUSTRIAL PARK,
SHANGHAI, CHINA,PC: 201600
TEL: 86 21 64261392/57746762 FAX: 86 21 51012181
