SDC 1511S - Typical System Wiring - Single Door (1511 S)

P:\INSTALLATION INST\Delayed Egress\INST-1511ST\INST-1511ST.vsd Rev G7 02-19 Page 6
Typical System Wiring –
Single Door (Model 1511S)
3 or 5
conductors
8 or 10
conductors
Power
Supply
To Fire Panel
AC Mains
2 conductors
PUSH UNTIL ALARM
SOUNDS. DOOR CAN BE
OPENED IN 15 SECONDS.
Key Switch or
Access Control
(Optional)
To Smoke
Detection System
2 conductors
600 Series
Power Supply
+
-
+
-
101-SP
Remote
Speaker
(OPTIONAL)
C NC
- +
-+
NC NONO C
C NC
NO CNO C
NO C NO C
NO C
NC NO
C NC
[ BAS ]
[ DPS ]
[RESET][RM TRIG]
[REX]
[RED RLY][GRN RLY]
[ LOCK ]
[ FP ]
[ PWR ]
J6
J7
J2
[IBO]
[EXT SPKR]
REMOVE J6 ONLY IF A FIRE
PANEL OR SMOKE DETECTION
SYSTEM IS CONNECTED TO
[FP] INPUT (Pg. 9)
918
Digital
Keypad
(OPTIONAL)
+
-
C
NO
Remote
Bypass/Reset
Display Modes
Door armed and locked.
Alarm countdown has ended,
door is unlocked and alarm sounding
until reset.
Door unlocked and alarm is shunted
(REX or Bypass)
Door has been opened after REX,
Bypass or Alarm.
15
00
--
--
--
--
AUX RELAY
MAIN RELAY
C
NO
400U-RMB
Remote
Buzzer
(OPTIONAL)
+
-
BLK
RED
GRN
OR G
BLU
WHT
